Amber Vision MA10

Features
The Amber Vision MA10 combines high-quality video recording with AI-based features like driver monitoring, ADAS alerts, and real-time event detection. Built for modern fleet operations, it enhances safety, improves driver behavior, and delivers actionable video insights.
Resolution: 720P AHD

Electronic Shutter (Auto), White Balance(Auto)

D-WDR, IR Night Vision
2.8mm (2.8 & 3.6 & 6.0mm optional)
12V Power Supply

Car Side Installation
IP67 Water & Dust Resistance
Spectrum Specifications
The Amber Vision MA10 supports 4G LTE connectivity with GSM fallback, enabling real-time video streaming and data transmission. With strong network compatibility, it ensures seamless communication and continuous monitoring across different environments.
Lens Module
1/4 CMOS Sensor
Resolution
720P
Format
PAL
Total Pixels
PAL:1280 (H) x 720 (V)
Minimum Illumination
0.1LUX / 0LUX with IR
Electronic Shutter
PAL: 1/50 〜 1/100,000s
GNSS Specifications
The Amber Vision MA10 utilizes GPS, GLONASS, and IRNSS positioning systems to provide accurate location tracking alongside video data. This enables precise trip tracking, route visibility, and improved incident analysis for better fleet monitoring.
Signal-to-noiseratio
> 46 dB
White Balance
Auto White Balance
Day/Night Switching
Color Mode
Digital Wide Dynamic
Turn on
Infrared Light
9 IR/850
Video Output
1.0Vp-p Composite Output, 75Ω
Lens
2.8MM
Viewing Angle
90°
Interface
M12 4-pole aviation connector
Other Specifications
The Amber Vision MA10 is built for durability and reliable performance, featuring a robust design suitable for continuous vehicle usage. It supports a wide input voltage range and integrates seamlessly with telematics systems for consistent video and tracking performance.
Power supply
DC 12V
Operating temperature
-20°C to +70°C
IngressProtection
IP67
Demo Video
FAQ
The Amber Vision MA10 is a 720P AHD external camera designed for vehicle safety and surveillance. It is specifically built for side vehicle monitoring, offering improved visibility and helping minimize blind spots. It is suitable for fleet monitoring, vehicle security, and accident prevention.
The Amber Vision MA10 offers a 720P resolution and a 90° viewing angle, ensuring clear and detailed video capture for external vehicle monitoring.
Yes, the camera is equipped with infrared (IR) night vision, allowing it to capture clear footage even in low-light conditions. It has a minimum illumination of 0.1 LUX and performs reliably in dark environments.
The Amber Vision MA10 has an IP67 rating, meaning it is fully protected against dust and can be submerged in water up to 1 meter for 30 minutes. This makes it highly durable and suitable for outdoor use.
Yes, it is designed to operate in temperatures ranging from -20°C to +70°C and can withstand varying humidity levels. The camera is built to endure harsh environmental conditions, ensuring reliable performance in diverse operational settings.
