- Up to 5 cameras monitor various angles providing a fuller view of the vehicle and its surroundings.
- ADAS and DMS capabilities provide tools to help improve driver safety and compliance.
- Strong 4G LTE connectivity enables real-time monitoring of the vehicles cameras via online platform.
- In addition to the road- and driver-facing cameras there are several different options for the 3rd and 4th cameras meaning there is a setup to suit any use case.
- Distraction Monitoring (DMS)
- The built-in gyroscope sensor detects harsh events such as harsh braking, speeding, sharp cornering, and collision; while the built-in camera of the ACC450 captures high-definition videos of these important incidents and sends the data to the cloud for later review and driver coaching
- The ADAS algorithm embedded enables the ACC450 to warn drivers of possible collisions to prevent safety-critical incidents and improve vehicle safety
- RS232 and relay ports provide support for optional accessories such as fuel and temperature sensors
- Automatically upload video clips or still images triggered by customizable key events such as unexpected vibration, ACC on/off, SOS button activation, etc
- In potential emergencies or compromising situations, pressing the in-cab panic button connected triggers immediate calls to chosen contacts and alerts to fleet managers, so they can act accordingly and quickly
- Dual micro SD slots provide a maximum of 512 GB on-device storage, allowing for up to 5 days 4 cameras recording simultaneously
DC 9-33V (Suitable for 12V and 24V vehicles)
1*Relay, 2*RS232, 2*Input, 1*AV-out
Operating temperature: -20℃to 70℃
Storage temperature: -30℃to 85℃
MicroSD/TF Card (Up to 256GB)
Built-In
Main Unit - Front camera: 1280x720/15FPS/F2.0/Full Colour /85° (HFoV),
Subcamera: 1280x720/15FPS/F2.5/Full Colour in daytime & monochrome in dim light/90° (HFoV)
.ts
